04 August 2010

Global

Equity Research

Diversified Metals & Mining (Metals & Mining) / OVERWEIGHT

Research Analysts Matthew Hope

61 2 8205 4669

matthew.hope@credit-suisse.com

Paul McTaggart

61 2 8205 4698

paul.mctaggart@credit-suisse.com



Commodities update



Copper - scarce mine supply

■ We see mined copper supply being short every year from now with the deficit reaching 770kt by 2013. We recently lifted our copper price in 2012-

13 to US$3.50/lb as we consider the shortage will tighten prices.  Mine supply in excess of our forecast will be needed to avoid a price spike.

■ There is risk that our existing mine supply forecast will under-deliver and intensify the shortage. Forecast mine additions from 2010-14 are the largest since 1994-99, but unlike the earlier period are not underpinned by large mines, rather numerous projects of 50-200ktpa Cu output. We examine the projects, but visibility on delivery drops away by 2012. In addition, we have noted that supply forecasts typically decline as the delivery period approaches and miner guidance is found to be over-optimistic.

■ We believe every possible copper project will be needed to fill the deficit, driving prices well above the cost curve. Looking at the lists of known but undeveloped copper projects, we need all the probable and approximately 25% of those possible in 2013 to fill our forecast deficit. Supply will be greatly stressed to deliver given many of the necessary projects are early stage.

■ Our base case demand growth of 6-7% p.a. from 2011-13 is more sustained than in recent years, but is conservative because it reflects synchronous growth as every region rises from the demand crater of 2009. We test a lower growth scenario, but in our view it implies sustained Western World recession and interrupted urbanisation in China.

Figure 1: Historic and forecast copper stocks & prices



1500 5.00



1200 4.00



900 3.00



600 2.00



300 1.00



0 0.00



Source: Brook Hunt, Credit Suisse estimates



Copper - scarce mine supply

Potential copper crunch by 2012

We see a major mined copper shortage starting this year and worsening  through  our forecast window to 2013. We see the shortage exhibited this year in refined copper draw- downs from exchange stockpiles combined with spot treatment charges for smelters approaching zero. Likewise in 2011, we expect constrained smelter output will see  the majority of the mine deficit become reduce refined zinc supply, so we expect to see a stockpile reduction of around 475kt next year. However, by 2012, we expect there will be insufficient global exchange stocks remaining to support the deficit that year. In our supply- demand model, to prevent the impossible situation of negative exchange stocks, we have   left the shortfalls as concentrate deficits of 380kt in 2012 and 770kt in 2013 (Figure 2, Figure 3). These are the amounts of additional mine supply that need to be found and brought into production to allow our refined copper balances to exist (Figure 5). Without this additional mined copper supply, we believe the world will face a copper crunch.

Figure 2: Copper supply and demand summary



Mine supply shortage in our supply-demand model, need additional copper-in- concentrate of 380kt in 2012 and 770kt in 2013 just to make it balance.



2005 2006 2007 2008 2009 2010f 2011f 2012f 2013f LT (2010 real)

Mine output kt 14,926 15,108 15,557 15,542 16,015 15,903 16,453 17,488 18,247

Change Y-o-Y 2.0% 1.2% 3.0% -0.1% 3.0% -0.7% 3.5% 6.3% 4.3%

Concentrate surplus/(deficit) kt 166 -141 -28 -22 5 6 -24 -377 -768

World refined production kt 16,573 17,288 18,028 18,329 18,353 18,332 19,058 20,815 22,214

Change Y-o-Y 4.1% 4.3% 4.3% 1.7% 0.1% -0.1% 4.0% 9.2% 6.7%

World consumption kt 16,920 17,442 17,984 17,916 17,474 18,361 19,533 20,875 22,215

Restocking kt 0 0 0 0 0 100 0 0 0

Change Y-o-Y -0.6% 3.1% 3.1% -0.4% -2.5% 5.6% 6.4% 6.9% 6.4%

China consumption kt 3,815 3,967 4,670 5,100 6,750 7,079 7,436 8,036 8,687

Change Y-o-Y 7.0% 4.0% 17.7% 9.2% 32.4% 4.9% 5.1% 8.1% 8.1%

Refined copper Balance kt -347 -154 44 413 879 -129 -475 -60 -1

Reported stocks kt 155 248 238 389 688 559 84 24 23

Stock/consumption wks 0.5 0.7 0.7 1.1 2.0 1.6 0.2 0.1 0.1

Copper price USD/t 3,680 6,696 7,140 6,932 5,149 6,954 7,716 7,716 7,716 4,850

Copper price USD/lb 1.67 3.04 3.24 3.14 2.34 3.15 3.50 3.50 3.50 2.20

Source: Brook Hunt, Credit Suisse estimates



Figure 3: Copper concentrate in shortfall 2012-13f Figure 4: Add'n mine supply not keeping up with demand



600



400



200



0



-200



-400



-600



-800



4 1,500

3 1,300

1,100

2 900

1 700

500

0

300

-1 100

-2 -100

-300

-3 -500



Source: Credit Suisse estimates, Brook Hunt Source: Credit Suisse estimates, Brook Hunt

Figure 5: Copper supply-demand shortfall caused by lack of mine supply

22,500



21,500





20,500





19,500





18,500







Exchange stocks (LME and SHFE) can fill 2010 and 2011 supply deficit; after that we will need more mine supply but have no visibility on potential projects that could come on.





17,500

2009 2010E 2011E 2012E 2013E



Source: Credit Suisse estimates, Brook Hunt

At present, we cannot identify the necessary mine supply to provide an additional 1.2Mt (380kt+770kt) of mine supply in 2012 and 2013, beyond that in our forecasts. We need a sense of urgency, such that some mine projects accelerate and "step forward" to shorten the current timings. For this acceleration, we consider strong copper prices will be needed as an incentive. Therefore in Credit Suisse Metals & Mining Equities team's recent Commodities Quarterly - "Stay long the Asia shorts" - 19 July 2010, copper prices were upgraded for 2012 and 2013 to US$3.50/lb on the forecast mine supply deficit.

So what happens if the mine shortfall of 380kt in 2012 and 770kt in 2013 is not brought forward? In that situation demand must be cut, and all available scrap will need to be collected. The driver of this would be a brutal copper price spike. We are not building a spike into our forecasts, instead expecting that a higher price will achieve the job. However, the situation will bear close attention.

It points to tough times for copper smelters & refineries

An implication of the mine supply shortage is that we see no relief in sight from margin pressure on copper smelters and refiners. Annual TC/RCs have dropped from US$95/9.5¢

+ 10% price participation in 2006 - the final year before price participation was eliminated, to $47/4.7¢ in 2010, and Oz Minerals is reporting US$39/3.9¢ for the 2010 mid-year contract. These amounts convert to a received price for a combined smelter and refinery treating 30% copper concentrate, of 46¢/lb in 2006 falling to 10¢/lb in 2H'10 with only the copper premium and excess acid sales to supplement this meagre fare.

How has the mine shortfall developed?

Ultimately, forecast mine shortfall is caused by copper demand increasing from the crater of 2009, faster than mine supply (Figure 4). In our previous April Commodities Quarterly, the deficit we forecast was lower, but we find that mine supply forecasts are down-graded as the forecast period approaches. Since April, the mine supply forecast has dropped by 250kt for 2011, and 100kt for following years. We look at the monthly revisions below.

Anatomy of the forecast mine supply revisions:

We derive our raw mine supply forecasts from Brook Hunt. How have these changed?

Figure 6: shows monthly mine supply forecasts for 2010 and 2011 (including probable projects) supplied by Brook Hunt. Raw 2010 production forecasts including highly probable and probable projects rose from April through to September 2009, peaking at 17.3Mt, but



If more copper projects do not appear and demand continues at the rate we expect, then we may see a copper shortage and price spike.

Unfavourable for copper smelters - expect low TC/RCs for the foreseeable future.



then fell away to 16.35Mt in June 2010. However, as 2010 is now underway, part of the drop includes delays and disruption that has occurred and been added to the forecast. We really need to compare what has happened if we anticipate disruption. In our forecasts, we incorporate a disruption factor that approximates 6% of supply, and reduce it on a monthly pro rata basis through the year as actual disruption occurs and is added to the forecast supply base. Using our output with disruption adjustments, we see that 2010 forecast still peaked in September 2009, but since then the forecast has been reasonably steady decreasing by only around 100kt since the January forecast.

Figure 6: Copper mine supply forecasts for 2010 & 2011 - reduce as the year approaches



Risk to our supply forecasts: Producers are over- optimistic and supply forecasts subside as delivery time approaches. 2011 forecasts beginning to ease.



Source: Brook Hunt, Credit Suisse estimates



For 2011, we still have the full 6% disruption factor applied. Figure 6 shows the forecast peaked in November 2009 at -16.7Mt, but has slid in recent months to -16.4Mt as project delays kick in. If 2010 is an appropriate analogy, would expect to see further reductions through until the third quarter as visibility increases and early forecasts prove too optimistic.

So what is built into the production forecasts?

We have seen above that mined copper supply forecasts tend to be down graded as the forecast period approaches. What does our +2011 forecast currently look like?

Figure 7 shows the additions to mined copper supply that have occurred since 1994 and extends into the forecast period. The first point immediately evident is there is a hump indicating a surge in additional mine supply forecast from 2010 to 2014. Looking at the detail in Figure 7, we can see the forecast increase will rely on mines with total output of less than 200ktpa and larger than 50kt, as indeed all the mine supply addition has since 2004. Copper supply from mines with output larger than 200ktpa output has been steady  to slightly declining since 2004. The large mine projects currently under feasibility will largely start after 2015.

We can further split up mined copper output into year-by-year additions (Figure 8).  Looking at the past, there was clearly a great leap in copper output from 1994 to 1999, which included increases at very large mines such as the doubling of output at Escondida and Grasberg and the start-up of Collohuasi. The copper supply jump caused a huge surplus, depressing the copper price, and consequently few mine starts occurred between 1999 and 2004. Prices rose and stocks dwindled in 2005, stimulating mine starts but the mines were small and in 2006 and 2008, copper addition from +50kt mines were less than mine reductions. From 2010 to 2014, the forecasts show another massive mined copper supply addition, but unlike 1994-1999, this is not built on large mines.



Is the supply hump real?

One needs to be a little sceptical whenever a large change is projected to conveniently begin in the near future. This is particularly the case in this instance because we have seen that supply forecasts tend to shrink as we move forward. It doesn't assist credibility that there are no large projects underpinning the mine supply additions. Instead numerous mines in the range of 50-200kt are responsible for the increases and all need to start on schedule to deliver the jump up in output.

Figure 7: Post-1994 mined copper supply addition by mine output size (kt Cu)



10,000



8,000



6,000



4,000



2,000



Jump in supply growth 2010-14 - is it real? Risk to delivery as noted above.

Supply growth 2010-14 from mines 50-200ktpa in output size.



Source: Credit Suisse estimates, Brook Hunt

Note: Copper addition will not sum to current supply as mine closures are not included.



Figure 8: Total additional copper from mine starts with output greater than 50kt



10 1,000

9 900

8 800

7 700

6 600

5 500

4 400

3 300

2 200

1 100

- -

-1 -100

-2 -200



Lot of projects needed to bring on our forecast supply

- will require consistently high prices.

But this supply is still not enough - it is built into the supply forecast and does not close the supply gap.



Source: Credit Suisse estimates, Brook Hunt

On the other hand, we can see a reason why there could be a supply jump: except for a brief period in the height of the GFC, we have experienced high copper prices since the start of 2006. Surely at some point these must stimulate a mine output increase?

Figure 8 shows us that this price-driven addition has not yet occurred. Perhaps the projects have all been progressing at similar rates and five years after the copper price rocketed in 2006, they are finally reaching production together to create the supply hump?. We need to look at the project list and assess the certainty of the start-ups and expansions. (Figure 9).

And let us be clear - these mine additions are already in our forecast. Our shortfall will be larger if any of these mines under-deliver.

Figure 9: +50kt mine additions forecast from 2010-2015 included in our supply balance



Maybe the supply jump is plausible - high prices since 2006 may have delivered more projects?



These mine additions must occur or we will be short copper.



Start-up Project Expansion/ Greenfields



Company Country Type Avg Prodn



Capex



Cu ktpa US$mn

2010 Los Pelambres Exp Antofagasta 60%/Japanese Chile Flot'n 110

2010 Andacollo Exp Teck (90%)/ENAMI Chile Flot'n 80 425

2010 Esperanza Green Antofagasta Chile Flot'n 198 2200

2010 Konkola Deep Exp Vedanta (79.4%), ZCCM 21% Zambia Flot'n 190 674

2010 KOV Green Katanga 75% Gecamines Congo SX/EW-flot'n 200 1216

2010 Las Cruces Green Inmet (70%)/ Leucadia Spain SX/EW 72 650

2011 Morenci SxEw Exp Freeport 85%/Sumitomo USA SXEW 56

2011 Antamina Exp BHP/ Xstrata/Teck/Mitsubishi, Peru Flot'n 125

2011 Los Bronces Exp Anglo American Chile Flot'n 180

2011 Cananea Re-start SCC Mexico Flot'n-SXEW 85

2011 El Teniente exp Exp Codelco Chile Flot'n 75

2011 Salobo I Green Vale Brazil Flot'n 127 1152

2011 Kinsevere-Nambulwa Exp Anvil 95% Congo SX/EW 60 380

2011 Bisha Green Nevsun 60%/State Eritrea Flot'n 55 250

2012 Jabal Sayid Green Citadel/CMCI Saudi Arabia Flot'n 60 250

2012 Boleo SxEw Green Baja (70%)/Korea res Mexico SX/EW 55 991

2012 Muliashi SxEw Green CNMC 85%/ZCCM-IH 15% Zambia 60 354

2013 Cadia Hill/Cadia East Exp Newcrest Australia Flot'n 50

2013 Caserones (ex Regalito) Green Pan Pacific Chile Flot'n-SX 170 1860

2013 Collahuasi 140-170kt/d exp Exp Xstrata (44%)/Anglo (44%) Japanese Chile Flot'n-SX 100

2013 Codelco Norte Hales Exp Codelco Chile SX/EW 165

2013 Toquepala 60-100kt/d exp Exp SCC Peru Flot'n-SX 85 616

2013 Oyu Tolgoi Green Ivanhoe/Rio Tinto Mongolia Flot'n 150 3500

2013 Tia Maria Green SCC Peru SX/EW 120 935

2013 Antapaccay (Tintaya Exp) Exp Xstrata Peru Flot'n-SX 160 1470

2013 Toromocho Green Chinalco Peru Flo'nt-SX 210 2200

2013 Tenke-Fungurume Exp Exp Freeport (57.8%), Lundin, Gecamines Congo SX/EW 55

2014 Mount Milligan Green Thompson Creek Canada Flot'n 44 917

2014 Bozshakol Green Kazakhmys Kazakhstan Flot'n 100 2000

Source: Brook Hunt, Company data, Credit Suisse estimates

Examining the mines supply additions

Figure 9 has a list of mine supply additions that will provide more than 50ktpa of contained copper and are forecast to start between 2010 and 2015. This list includes both approved new mine starts and expansions, and unapproved but likely expansions and start ups. We are looking at output increases, but it should be kept in mind that large mines such as

Andina and Escondida can have annual production variances of greater than 50ktpa. We exclude from the table projects that replace output from one source with another, but have no change in expected overall output - such as El Abra's development of the sulphide reserves. Of the large projects, we have included only the underground section of Oyu Tolgoi that we expect to start up before 2015. We provide an update of large projects at the end of this note. The majority that ultimately come on stream will hit supply after 2015.

2010 and 2011 good visibility

Looking at the projects in Figure 9, there is obviously strong certainty over the mines due to start this year. The expansion of Antofagasta's Los Pelambres mine is complete and the ramp up reached the planned rate by end of 1Q 2010. The new Esperanza and Andacollo expansions are Chilean porphyry projects reaching development. Esperanza is innovative in side-stepping the Chilean water shortage by piping up seawater. Vedanta has been progressing the development of Konkola Deeps for a number of years and it is finally reaching production. Inmet's Las Cruces in Spain actually started in 2009, but ramp up  has been troubled and slow, probably due to the innovative processing technique. Las Cruces has high grade sulphide ore (6.2% copper) but also high deleterious smelter penalty elements, so bacterial oxidation of the sulphide followed by SX/EW is being used to produce cathode copper on site. Inmet's latest estimate is that it will reach design rate by the end of CY10. The project we consider to have the least certainty is KOV, where in late-2009 Katanga Mining adopted a fast-tracking of the new open cut, years ahead of the previous plan. Mining has commenced but the operations are behind schedule due to summer rains.

In 2011, we are confident about Anglo's 260kt expansion of Los Bronces, which is a straightforward expansion of a large existing mine. For similar reasons we are also confident over the 125ktpa expansion of Antamina in Peru and Freeport's 56ktpa expansion of Morenci. Vale's Salobo is a new mine and the Kinsevere expansion project has smaller operators than others, but they appear to be progressing well. The Bisha project is under construction and reported to be on schedule for first production in 2011, although output is conservatively pushed back to 2012 in our forecasts. The project has a twelve year life although copper output is only expected to exceed 70ktpa in the first three years, then decline to less than 20ktpa.

There is a little more uncertainty over Cananea in Mexico. It is a restart of an existing mine rather than an expansion. The operation has been closed since early-2007 by a strike that evolved into a bitter union versus government struggle. The mine blockade was finally cleared by the Government earlier this year and Southern Copper Corporation is  assessing the damage and necessary repairs. We expect it will reopen next year, but the main risk we see would be further insurrection from former mine workers.

We expect El Teniente to gradually expand from around 400ktpa to 475ktpa by 2013 through a mill debottlenecking, but there is little certainty. Codelco has had major expansion plans for years, but production remains rather static due to insufficient investment given the Chilean Government's need for funds.

By 2012: supply certainty drops away

As we reach 2012, the certainty in the new projects drops away: Citadel has only in the last few weeks raised money to begin the Jabal Sayid; we have not heard a great deal about Muliashi since China Non-ferrous Metals bought the controlling stake, and Boleo is  a large deposit with unusual mineralisation being progressed by a small company with all the financial and operational risks that entails.

The list of new mines forecast for 2013 is even less certain. We have reasonable confidence in the Tia Maria project, despite the local opposition that has already delayed the project; and likewise for Xstrata's Tintaya (Antapaccay) and SCC's Toquepala expansions provided they manage water issues. Oyu Tolgoi is high profile and will undoubtedly proceed, with first production around 2013. Our table only lists the production



Big +200ktpa projects are largely 2015 and beyond developments.



High level of certainty on 2010 and 2011

developments in Figure 9.



Delivery certainty on projects in Figure 9 drops away by 2012.



rate we expect from Oyu Tolgoi by 2015; the project has a five year ramp up to peak production. The feasibility study for the mill throughput expansion at Collohuasi is yet to be completed, but appears likely as the addition of 100ktpa copper is needed to maintain output that will otherwise decline from the peak reached in 2009. We expect the greatest challenge will be sourcing additional process water.

Newcrest's Cadia East involves replacing output from the Cadia Hill open cut with ore from the Cadia East underground, the latter to be mined by panel caving. Until the ore has begun to cave successfully, there remains technical risk. Freeport will only begin the feasibility study into a 50% expansion of Tenke Fungurume this year following the production start last year. The extreme sovereign risk in Congo highlighted by First Quantum's experience (it has been stripped of the Kolwezi project after investing US$750mn and Congo's Supreme Court has challenged its ownership of the Frontier mine where it invested US$300mn) will no doubt play a role in any investment decision. Toromocho in Peru has the benefit of a Chinese owner with deep pockets and great construction experience, but the disadvantages of very high capex, unimpressive grade and the need to relocate 5000 residents. Caserones has even lower grade than Toromocho with equivalent capex, but as far as we are aware, Pan Pacific has decided to proceed. Codelco's Nortes Hales is a little cryptic; Hales appears to be a life extension to a current SX/EW project at Norte.

Kazakhmys appears to be intent on starting Bozshakol in 2014, but we regard the mining of Mount Milligan as speculative. In any event, Mount Milligan is only expected to exceed 50kt in one year.

So, even within our current mine forecast, there is some uncertainty, and potential for delays that would increase our mine supply deficits.

How could the mined copper deficits be filled

We have now assessed the ore additions in the supply hump, but we still have not addressed the mined copper shortfalls in our balance - 380kt in 2012 and 770ktpa by 2013. What is available?

The probable project list

Commodity consultants Brook Hunt provide a list of probable copper projects that would provide a total of 477kt in 2013 if they all started at the rate in the list. The mines range from the likely - 50kt from an underground expansion at Ernest Henry which Xstrata has put back on the cards following the abandoning of the Australian Government's proposed super tax, to the unlikely - 70ktpa from a restart of BHP's closed Pinto Valley and 65ktpa from the first production from Gold Corp/ New Gold's El Morro deposit in Chile (450Mt at 0.46% copper, 0.58g/t gold). To the best of our knowledge BHP is not considering Pinto, and a recent Goldcorp investor day presentation shows El Morro as potential post-2014 growth. Subtract those two alone and we have less than half our 2013 deficit in the entire probable list.

The possible project list

We now have to move to the most tenuous category of future mines, Brook Hunt's list of "possibles". The sum of production from possible mines in 2013 is 1.42Mt of copper from 65 projects, very few of which we have heard of, six of which are additions greater than 50ktpa in 2013 with the maximum being 83kt from Bahuerachi in Mexico. Scanning this list of hopefuls, it's difficult to conceive they could have any chance of being in production by 2012 or 2013, given their status remains so tenuous.



Figure 9 lists projects already in our forecast. What can we use to fill the mine supply deficit?



There are not enough probable projects to fill the deficit.



Need to use the possible projects, but there is currently scant likelihood that these will start by the 2012 timeline



Figure 10: Probable' &'possible' mine projects needed to fill additional requirement

1,800

1,600

1,400

1,200

1,000

800

600

400

200

0



Not enough probable projects to fill deficit. Have to look for possibles.



Need a price-driven sense of urgency to bring these on in time.



2011 2012 2013



Source: Brook Hunt, Credit Suisse estimates



Our conclusion from looking at the supply side

Our supply demand forecast includes a strong growth in output from the mine supply side, particularly in 2013, growth that may not be realised. And even if all the projects do come through as scheduled, we will still have a mine supply gap that is unfilled, reaching  770ktpa by 2013.

Having searched the lists for projects could fill this supply gap, we find that there really is very little available. We have to include projects from the most tenuous category to meet the demand. Realistically, there is little chance of a project that has not started a feasibility study being brought on in the three-year time frame available.

Figure 11: 2010 copper costs curve C3 total costs (normal basis)

350



300



250



200



150

Mine supply is desperate and will over-ride opex and cost curve considerations. Our US$3.50/lb price is the top of the C3 (total) cost curve.





100



50



0

0 2500 5000 7500 10000 12500

Cumulative Production copper (kt)



Source: Brook Hunt, Credit Suisse estimate



So if our demand forecast is correct, we need every mine that is available to enter production. This then, is not a story about marginal costs - the copper cost curve has no relevance. This is about supply irrespective of opex. A price far above the cost curve is a necessity to bring on the projects. Accordingly we've pushed up our 2012 and 2013 price



forecasts and have them flat lining at US$3.50/lb, which for reference is the very top of the C3 (total costs), cost curve, where it goes exponential (Figure 11).

The copper situation will bear watching closely. If we advance towards 2013 and supply does not come on line as needed, there could well be a situation where supply cannot meet demand and is bid up into a price spike that then acts to crush unsustainable demand and provides an incentive to collect every piece of scrap into supply. This is not our forecast at present, but we will watch the supply-demand intently.

Testing our demand forecast

So looking for where we could be wrong, is our demand forecast realistic?

For the purposes of this analysis, we ignore 2010 - the year is more than half gone and LME stocks have been falling since mid-February; total exchange stocks since March, and the total balance has dropped -165kt YTD. Unless there is a stunning turn around in the second half, it appears that stocks will end the year lower, indicating a deficit.

Our forecast global consumption for 2011 is an increase of 6.4% YoY, 6.9% YoY in 2012 and 6.4% in 2013 (Figure 2, Figure 16). These are stronger figures than we have seen in recent years. While larger annual increases have occurred in the past, for instance 9.3% YoY growth in 2004 our estimated demand growth is more sustained than any period  since the 1995-97. Why so?

Clearly these are not normal times. The global economy is still hauling itself from the Great Recession in which every developed country suffered massive demand destruction. Recovery is erratic, operating at different speeds, and remains uncertain, but the Credit Suisse house view of our economists and strategists is that double dips are most unlikely and recovery is inevitable unless there is another financial shock to cut it off.

Synchronous growth

What we have in our demand scenario is synchronous growth in every market, which is very different to the case before the GFC, and it is that which causes the stronger global growth figures.

Since 2000, copper consumption in developed economies had peaked. If we ignore minor developing economies, a proxy to see this is the world ex-China (Figure 12). Copper consumption rose in the late-1990's through the dot-com boom, retreated after the bust and then levelled off until the GFC. Behind the overall global stability, what actually occurred was that copper consumption moved in different directions across the regions. Copper consumption in the US declined every year following 2000 as industry migrated overseas, whereas Japan and Europe were up and down though the period (Figure 13). But during the GFC, consumption was decimated in every developed world region so that the only direction now possible is up. Therefore, we have synchronized growth and that boosts the global percentage to a level higher than in the past.



If new supply does not appear we will be looking for a price spike.



Where could we be wrong?

Looking at our demand forecast.



Our +6% consumption forecast for 2011-13 reflects synchronous demand growth as all developed regions gradually recover from 2009 demand chasm.

Figure 12: Global copper consumption

25



20



World ex-China copper

15 consumption levelled off

before GFC. Reflected

10 some areas increasing,

others falling.

5



0



Source: Brook Hunt, Credit Suisse estimates



Figure 13: Global copper consumption YoY growth/(decline) developed economies

30%



20%



10%



0%



-10%



After the GFC. All developed world copper consumption is climbing up from the precipitous 2009 drop.





-20%



-30%



-40%



Source: Brook Hunt, Credit Suisse estimates



What we have not seen is the rapid rebound in demand that occurred in the year following the 1975 recession which caused a demand crash of similar magnitude to 2009 (Figure 19). The 1976 bounce was 15% globally, 17.5% in the OECD. This time around, current macro events make it evident that recovery is taking a longer, harder road. The property overhang  in the US is keeping housing starts low and developed world consumers remain cautious.

At our forecast growth rates, absolute copper consumption in Western Europe will only claw its way back to 1990 levels by 2013 while North America will make it to 1986 levels (Figure 20). In assessing what these dates represent, one must keep in mind the increased intensity of copper wiring in modern houses compared to three decades ago, for greater appliances and air conditioners, computers, network cables and recharging points for mobile phones in every room.



And then there is the China factor:

China's rapid growth has made it the largest copper consumer, rising from 8% of global demand in 1992, to an estimated 39% in 2010. Copper growth in China now has a huge influence on global growth.

Figure 14: Copper usage per capita GDP

22

20

18

16

14

12

10

8

6

4

2

0



Urbanised China copper consumption is approaching developed world levels, but overall China has a long way to go. Urbanisation is continuing in Tier 3 and Tier 4 cities.



0 5 10 15 20 25 30 35

GDP,  USDk 1990 base



Source: IMF, Credit Suisse estimates, Brook Hunt



Per capita copper consumption and GDP

On a per capita basis, the US consumption has been falling since 2000 (Figure 14). This is due to the migration of manufacturing industries to the developing world, particularly China. The trend of falling copper is likely to be maintained, but 2009 was especially low due to housing starts reaching their nadir and the cessation of other industrial production such as vehicle manufacturing. Ultimately the recovery of housing starts and the vehicle industry should slow the decline.

Export manufacturer Germany has stayed on trend. Its per capita consumption dropped in 2009, but only in line with the GDP. Japan's consumption in 2009 formed a very low outlier compared to the previous tight distribution, so recovery should be expected. Korea per capita copper consumption peaked in 2004. Subsequently its copper consumption has dropped sharply as its per capita GDP approached developed nations so it appears it will end up with Japanese style figures.

China is an interesting case. On our estimates, urban China copper consumption is beginning to reach Western levels. At some point it would be expected to roll over to lower growth, but at present, China remains the world's factory so we would expect a trend more like Korea or Germany, reaching great heights before turning down. However, total China copper consumption remains low per capita. China continues to urbanise and is now focussing on the Tier 3 and 4 cities, and the West of the country, so copper consumption will continue to rise.

What if - how would demand look if it was lower than we forecast?

It is worthwhile testing our estimates by cutting demand forecasts to see whether a lower amount appears plausible. For the purposes of analysis, we look to cut around 400-800ktpa from years 2011 to 2013, to maintain the refined balance roughly where it is.



We test our demand estimates with a low demand case scenario.



In 2011, our growth for China is 5.1%, or 360kt, so we cannot take the amount the entire 400kt from China without the implausible assumption that copper consumption will fall. But we could take 140kt from 2011 if we assume the Government induced slow-down will be sufficiently extreme to cut consumption growth to 3.1%. Cutting 290kt from 2012 and 2013 maintains 6.2% and 8.4% y-o-y growth rates that appear possible, if well below the average 16.5% growth rates achieved from 2000-2009 (Figure 18).

Copper demand growth in North America could be trimmed further if we assume that recovery in housing starts will be delayed beyond 2011. We could cut 100kt in 2011 and bring consumption back to 5.5%, the same as our estimate for 2010 and 110kt in the following years that would cut further year's growth to 6%. We also cut 40kt from Japan in 2011 and 50kt from following years; For Western Europe: 65kt in 2011 and 110kt from the following years; Eastern Europe: 20kt and 30kt the following years; Other Asia 60kt in 2011, 125kt in 2012 and 194kt in 2012.

India we choose to leave untouched. Firstly, its copper consumption is not yet sufficiently large that a cut would greatly affect global balances. Furthermore, with a number of five year plans focusing on increasing electricity supply, using coal fired and nuclear generators, and consequently necessary electricity distribution and use, we consider there is little realistic chance of India having lower copper consumption than our y-o-y growth of 8%.

Overall, for our low case we cut 417kt in 2011, 706kt from 2011, and 791kt in 2013.



Figure 15: Low demand case balances



Our low case trims copper consumption from major demand regions in 2011- 2013E.



2005 2006 2007 2008 2009 2010f 2011f 2012f 2013f

Concentrate surplus/(deficit) kt 166 -141 -28 -22 5 6 -2 43 -39

World consumption kt 16,920 17,442 17,984 17,916 17,474 18,361 19,116 20,169 21,424

Restocking kt 0 0 0 0 0 100 0 0 0

Change Y-o-Y -0.6% 3.1% 3.1% -0.4% -2.5% 5.6% 4.1% 5.5% 6.2%

China consumption kt 3,815 3,967 4,670 5,100 6,750 7,079 7,300 7,750 8,400

Change Y-o-Y 7.0% 4.0% 17.7% 9.2% 32.4% 4.9% 3.1% 6.2% 8.4%

Refined Copper Balance kt -347 -154 44 413 879 -129 -84 137 -95

Reported stocks kt 155 248 238 389 688 559 475 612 517

Stock/consumption wks 0.5 0.7 0.7 1.1 2.0 1.6 1.3 1.6 1.3

Source: Credit Suisse estimates



Figure 16: Base case copper consumption Figure 17: Low demand case copper consumption

2009 2010f 2011f 2012f 2013f 2009 2010f 2011f 2012f 2013f

Africa 6.1% 7.4% 7.0% 6.5% 6.6% Africa 6.1% 7.4% 7.0% 6.5% 6.6%

North America -22.9% 5.5% 11.1% 6.0% 6.7% North America -22.9% 5.5% 5.5% 6.0% 6.7%

Latin America -11.9% 7.4% 7.0% 6.5% 6.6% Latin America -11.9% 7.4% 7.0% 6.5% 6.6%

Japan -26.9% 11.9% 9.0% 7.9% 4.6% Japan -26.9% 11.9% 4.9% 7.0% 4.5%

South Korea 5.9% 3.1% 6.4% 5.7% 2.4% South Korea 5.9% 3.1% 6.4% 5.7% 2.4%

China 32.4% 4.9% 5.1% 8.1% 8.1% China 32.4% 4.9% 3.1% 6.2% 8.4%

India 4.3% 21.3% 7.3% 8.1% 8.4% India 4.3% 21.3% 7.3% 8.1% 8.4%

Other Asia -6.6% 7.4% 7.0% 6.5% 6.6% Other Asia -6.6% 7.4% 4.4% 3.8% 4.1%

Western Europe -19.5% -0.7% 5.1% 5.1% 3.7% Western Europe -19.5% -0.7% 2.8% 3.6% 3.7%

East/Central Europe -35.8% -0.7% 5.1% 5.1% 3.7% East/Central Europe -35.8% -0.7% 2.4% 3.9% 3.7%

Oceania -14.6% 7.4% 7.0% 6.5% 6.6% Oceania -14.6% 7.4% 7.0% 6.5% 6.6%

World -2.5% 5.1% 6.4% 6.9% 6.4% World -2.5% 5.1% 4.1% 5.5% 6.2%

World ex China -16.3% 5.2% 7.2% 6.1% 5.4% World ex China -16.3% 5.2% 4.7% 5.1% 4.9%

Western World -14.4% 5.7% 7.4% 6.2% 5.5% Western World -14.4% 5.7% 4.9% 5.2% 5.0%

Source: Credit Suisse estimates Source: Credit Suisse estimates



Our low demand case would produce refined copper deficits and surpluses between 2011 and 2013 that would leave copper stocks reduced by only 40kt from our estimate for 2010 (Figure 15). What it means for y-o-y % changes can be seen by comparing Figure 16 with Figure 17.



Evaluating the low case

In assessing the reasonableness of this low case option, we see that lower demand is plausible, but only if we assume further urbanisation and development in China is delayed for 2011 and 2012 at least. There are few new power stations and not a great deal of retail electricity distribution in tier 3 cities with 3-6% growth. Comparing China's copper growth rates in the past with what is forecast, we see that our base forecast is already far below previous years particularly since the post-2000 boom. The 3.1% of the low case begins to look most unlikely (Figure 18).



Low case would take China consumption to 3% in 2011

and 6% in 2012 - basically a halt to urbanisation.



Figure 18:China YoY copper demand +forecasts Figure 19: World recessions - Cu demand YoY



35%



30%



25%



20%



15%



10%



5%



0%



-5%



20%



15%



10%



5%



0%



-5%



-10%



-15%



-20%



1 2 3 4 5 6 7 8





Source: Brook Hunt, Credit Suisse estimates Source: Brook Hunt, Credit Suisse estimates

Note that the low consumption growth shown for China in 2006 is probably not correct. That year saw the short-selling controversy where Liu Qibing, a trader acting on behalf of China's secretive State Reserve Bureau (SRB) short-sold several hundred thousand tonnes of copper on the LME and was caught on the wrong side of the trade. China begrudgingly ultimately settled these trades apparently by physical delivery from its hidden stockpiles at the SRB. The appearance of this copper in export statistics as it left the country made apparent consumption calculations excessively low.

For the developed nations, the low consumption case we have devised would require global industry to remain devastated from the GFC for a longer period without real recovery. The low case would push absolute copper consumption by 2013 in Western Europe back a year to 1989 levels versus 1990 for the base case. North America would  fall two years to 1984 levels versus 1986 for the base case (Figure 20).



Comparing our forecast Western World recovery with comparable 1976 shows it is lethargic. Much slower would require a Japan style non-recovery.



Figure 20: Developed countries absolute copper usage + base & low case forecasts



4,500

4,000

3,500

3,000

2,500

2,000

1,500

1,000

500

0



On our demand forecasts, by 2013 Europe gets back to 1990 absolute copper consumption levels and North America to 1986.

Low demand case would push that back a couple of years.



Source: Brook Hunt, Credit Suisse estimates



We can assess the US numbers in a little more detail:

US housing starts have been scudding along at an annualized rate of around 500k per annum since the start of 2009, after falling from around 2,000k pa throughout 2005 (Figure 21). In an average US house, there is approximately 200kg of copper. So in 2005, with 2m housing starts, we can estimate that 400kt was used in new houses and 1.9Mt for other uses out of the total US copper consumption of 2.3Mt. With housing starts at 500k pa since the start of 2009, that represents around 100ktpa of copper leaving 1.5Mtpa for other uses on our 2010 estimates. We assume that a modest but real recovery should see at least 1m housing starts and 1.8Mt of copper for other uses in the medium term, or a total  of 2Mtpa of copper consumption by 2013. This is our base case for 2013 using our percentage increases. However, the low case leaves us 100kt short by 2013, representing either no housing starts recovery or industry well below 2006 and 2007 levels.

Figure 21: US housing starts

2,500



2,000





1,500





1,000



Eventually US housing will have to pick up and that will see copper demand recover.

There is roughly 200kg in an average US house.





500



0



Source: Company data, Credit Suisse estimates





Similarly, European growth of any type would be weak, with growth out of the -20% GFC chasm occurring at only 3-4% pa. This would seem to push our U shaped recovery into something more akin to an L.

What does this demand-side analysis tell us?

A low case demand scenario would be plausible in the case of a double dip recession, a recession in China, or if we assume Japanese-style long-term depression is underway for the developed world. But if we follow the CS House view that recovery  should  occur provided regulators don't induce a financial shock, then the low case is too low, and even our base case looks a stretch to the low side.

2015+, Status of the big copper projects

For completeness, we also provide a summary of the status of the big future copper projects. In summary many of these will probably start, but they are really 2015 and beyond stories, and do not assist the copper balances in the short to medium term.

Oyu Tolgoi. With development now approved to commence, we expect to see a 2013 start, followed by a five year ramp up to full production of 550kt from the underground and open cut workings closer to the end of the decade.

Las Bambas - An Xstrata development in Peru that was just approved (3 August 2010). Las Bambas has a mineral resource of 1.13bnt at a grade of 0.77% copper. The company expects final Government approvals in the first half of 2011, a construction start in 3Q  2011 and first production in mid-2014, ramping up to is suggesting possible approval in 2011 and a late-2014 start, ramping up to 400ktpa. We always expect delays so we see it as one of the first of the 2015+ starts.

Collohuasi - Anglo and Xstrata recently announced a 40% increase in resources of this 500ktpa mine to over 7bnt. They announced an expansion study to be completed by 1Q 2011, looking at increasing the output by 500ktpa to a total of over 1Mtpa. Such a 500ktpa increase would not be fast or cheap, and has not yet been approved. We expect it would take 3-4 years to see an output lift, taking it to around 2015.

Pebble - this Anglo/Northern Dynasty project located 320km southwest of Anchorage in Alaska is a vast 5.9bn tonne porphyry copper-gold-molybdenum resource with 0.78% CuEQ. It is still being explored with a prefeasibility report underway so any development remains distant, but Anglo has suggested a potential copper output of around 350ktpa. Given its location, near salmon spawning grounds, and with a number of NGOs opposing the development, permitting may be an issue. Any production start would be late in the decade.

La Granja - In 2008, Rio Tinto inferred a resource of 2.77bnt grading 0.51% copper. The project was previously owned by BHP, but it walked away in the early 1990s when copper prices were low after finding the deposit had high arsenic, poor leaching characteristics and a deficit of flat ground in the mountainous terrain on which to place leach pads. Rio won the deposit on tender from the Government in 2007 and is continuing the study. If it proceeds, an innovative leach process is likely to be used to leave the arsenic behind.

Olympic Dam expansion - this is a potential mega-project that would consume vast amounts of capital, probably becoming the most capital intensive mine on the planet. The details previously released had a staged development with five years of pre-stripping required to remove 300 metres of sandstone cover to reach the top of the ore body. Presumably every subsequent stage would require similar periods to cut back the pit walls and increase ore exposure. The current plant and smelter/refinery would be replaced and expanded. Water and power are only two of the many factors that require intense consideration.





Resolution - Rio Tinto estimated an inferred resource of 1.34bnt grading 1.51% copper and 0.04% Molybdenum. Rio is guiding towards a 2020 start i.e. beyond the tenure of the current management and board. Resolution is an impressive resource, but would require an equally impressive mining development to proceed. The orebody is 1500-2000 metres below the surface, and with rock temperatures of 85°C, Rio would need to issue oven mits.

Tampakan - WMC made this discovery in the early 1990's, but ultimately abandoned it due to a low-level Marxist insurgency stewing away in its locality on Mindanao Island in the Philippines, and an inability to win over local land-owners. Xstrata picked it up and delivered a feasibility study proposing production of 340ktpa of copper and 350koz of gold for a massive investment of US5.2bn, but has recently run into a road-block, with the out- going Governor of the province approving an environmental code that bans open-pit mining. Tampakan caps a ridge and could only be mined via open cut. The incoming Governor will review the ban. Xstrata was targeting first production by around 2016 but  that is now contingent on political developments.

Aynak - Location has not stopped Chinese investors from commencing work on the large Aynak deposit, about 100km from Kabul in Afghanistan, with the first stage of mine and explosive ordinance removal having been completed. Aynak was opened to tender and received a number of bids, but was won by a JV consortium of CNMC and Jianxi copper.  A 2015 start with a five year ramp up to 300kt looks probable, provided the region remains somewhat stable.

Reko Diq - Another monster deposit in one of the world's less desirable locations: about 50km south of the Afghanistan border in Balochistan Province, North Western Pakistan. The deposit is owned by Antofagasta, Barrick and 25% by the Balochistan Government and has an estimated 4.1bnt grading 0.50% Cu and 0.3g/t gold. A feasibility study suggested production of 200ktpa of copper and 250koz of gold at a cost of US$3.3bn. It appears there may be some negotiations ahead for this project, so we suspect it will be another potential starter late in the decade. The Daily Times of Pakistan quoted an official saying the Provincial Government may wish to see a refinery built to accompany the mine, which the companies ruled out. Even if the Province chooses to build a refinery itself, some non-commercial concentrate sales would be suspected, so this is an unfavourable development.

Conclusions and takeaways

■ On our copper demand forecast, we are approaching a period where currently visible copper supply will not meet demand. Mined copper supply is the constraint.

■ The deficit is already underway in 2010, but should be filled to the end of 2011 by copper stocks on commercial exchanges. By 2012, we will need more mine supply than is built into our current forecast. We have no visibility on what these projects will be.

■ Large (+400ktpa) mined copper projects are 2015 and beyond propositions.

■ Mined copper growth between 2010 and 2015 will be derived from a large number of projects with between 50ktpa and 200ktpa output. The visible projects form a notable jump in supply growth above previous growth rates.

■ All of these projects, plus others that are not yet approaching development decision, will be needed to meet demand until the end of our 2013 demand forecast.

■ Consistently strong prices will be needed for all the projects to stay on track and for new projects to accelerate exploration and feasibility and join the development list.

■ There is a high risk that the current visible projects will not meet the development schedule. We have seen that supply estimates tend to be scaled back as actual development tends to take longer than estimated.





■ If the supply schedule is not met, there is risk that the copper shortfall would see prices spike as the scarce resource is bid up. We will be watching In terms of demand, we have examined our forecast and believe it is conservative. Our 6-7% global growth figures look strong, but really represent synchronous growth as all developed regions gradually recover from the demand chasm of the 2009 Great Recession.

■ Clearly, we have not seen a rapid rebound in demand such as the +15% growth that followed the 1975 recession, which was of similar magnitude to the GFC. Our 6-7% growth levels will by 2013, only return us to 1986 absolute consumption levels for North America and 1990 levels for Western Europe.

■ On a per capita growth chart it is apparent that China still has a lot of copper growth required to reach developed country levels, but we expect that growth will now focus on Tier 3 and Tier 4 cities becuse the urbanised population is approaching developed country consumption levels. Our China copper growth of 5-8% is significantly slower than previous years and in our view is conservative.







Companies Mentioned  (Price as of 03 Aug 10)

Anglo American plc (AAL.L, 2627.00 p, NEUTRAL [V], TP 3000.00 p, OVERWEIGHT) Antofagasta (ANTO.L, 1037.00 p, NEUTRAL [V], TP 1250.00 p, OVERWEIGHT)

BHP Billiton (BLT.L, 2034.50 p, NEUTRAL [V], TP 2300.00 p, OVERWEIGHT) BHP Billiton Limited (BHP.AX, A$40.98, NEUTRAL, TP A$45.00)

First Quantum Minerals Ltd. (FM.TO, C$64.42, OUTPERFORM [V], TP C$90.00) Freeport-McMoRan Copper & Gold (FCX, $74.80, OUTPERFORM [V], TP $95.00) Inmet Mining Corp (IMN.TO, C$50.25, NEUTRAL [V], TP C$65.00)

Ivanhoe Mines Ltd. (IVN.TO, C$18.14)

Kazakhmys Plc (KAZ.L, 1278.00 p, OUTPERFORM [V], TP 1650.00 p, OVERWEIGHT) Lundin Mining Inc (LUN.TO, C$4.00, OUTPERFORM [V], TP C$6.50)

Minmetals Development Co. Ltd (600058.SS, Rmb16.88)

Mitsubishi Materials (5711, ¥228, OUTPERFORM [V], TP ¥320, OVERWEIGHT) Newcrest Mining (NCM.AX, A$33.41, OUTPERFORM, TP A$47.00)

Rio Tinto Limited (RIO.AX, A$73.00, OUTPERFORM [V], TP A$85.00)

Rio Tinto Limited/PLC (RIO.L, 3450.00 p, OUTPERFORM [V], TP 4500.00 p, OVERWEIGHT)

Southern Copper Corporation (SCCO, $32.39, OUTPERFORM [V], TP $37.00) Teck Resources Ltd. (TCKb.TO, C$36.19, OUTPERFORM [V], TP C$52.00)

Thompson Creek Metals Co. Inc. (TCM.TO, C$9.48, OUTPERFORM [V], TP C$16.00) Vale (VALE, $29.07, OUTPERFORM [V], TP $36.00)

Vedanta Resources PLC (VED.L, 2568.00 p, OUTPERFORM [V], TP 3400.00 p, OVERWEIGHT) Xstrata Plc (XTA.L, 1075.00 p, OUTPERFORM [V], TP 1450.00 p, OVERWEIGHT)

Disclosure Appendix

Important Global Disclosures

I, Matthew Hope, certify that (1) the views expressed in this report accurately reflect my personal views about all of the subject companies and securities and (2) no part of my compensation was, is or will be directly or indirectly related to the specific recommendations or views expressed in this report

The analyst(s) responsible for preparing this research report received compensation that is based upon various factors including Credit Suisse's total revenues, a portion of which are generated by Credit Suisse's investment banking activities



Analysts' stock ratings are defined as follows:

Outperform (O): The stock's total return is expected to outperform the relevant benchmark* by at least 10-15% (or more, depending on perceived risk) over the next 12 months

Neutral (N): The stock's total return is expected to be in line with the relevant benchmark* (range of 土 10-15%) over the next 12 months

Underperform (U): The stock's total return is expected to underperform the relevant benchmark* by 10-15% or more over the next 12 months

*Relevant benchmark by region: As of 29th May 2009, Australia, New Zealand, U.S. and Canadian ratings are based on (1) a stock's absolute total return potential to its current share price and (2) the relative attractiveness of a stock's total return potential within an analyst's coverage universe**, with Outperforms representing the most attractive, Neutrals the less attractive, and Underperforms the least attractive investment opportunities. Some U.S. and Canadian ratings may fall outside the absolute total return ranges defined above, depending on market conditions and industry factors. For Latin American, Japanese, and non-Japan Asia stocks, ratings are based on a stock's total return relative to the average total return of the relevant country or regional benchmark; for European stocks, ratings are based on a stock's total return relative to the analyst's coverage universe**. For Australian and New Zealand stocks a 22% and a 12% threshold replace the 10-15% level in the Outperform and Underperform stock rating definitions, respectively, subject to analysts' perceived risk. The 22% and 12% thresholds replace the +10-15% and -10-15% levels in the Neutral stock rating definition, respectively, subject to analysts' perceived risk.

**An analyst's coverage universe consists of all companies covered by the analyst within the relevant sector.

Restricted (R): In certain circumstances, Credit Suisse policy and/or applicable law and regulations preclude certain types of communications, including an investment recommendation, during the course of Credit Suisse's engagement in an investment banking transaction and in certain other circumstances



Volatility Indicator [VJ: A stock is defined as volatile if the stock price has moved up or down by 20% or more in a month in at least 8 of the past 24 months or the analyst expects significant volatility going forward

Analysts' coverage universe weightings are distinct from analysts' stock ratings and are based on the expected performance of an analyst's coverage universe* versus the relevant broad market benchmark**:

Overweight: Industry expected to outperform the relevant broad market benchmark over the next 12 months

Market Weight: Industry expected to perform in-line with the relevant broad market benchmark over the next 12 months

Underweight: Industry expected to underperform the relevant broad market benchmark over the next 12 months

*An analyst's coverage universe consists of all companies covered by the analyst within the relevant sector.

**The broad market benchmark is based on the expected return of the local market index (e.g., the S&P 500 in the U.S.) over the next 12 months.







Credit Suisse's distribution of stock ratings (and banking clients) is:

Global Ratings Distribution Outperform/Buy* 47% (63% banking clients)

Neutral/Hold* 40% (59% banking clients)

Underperform/Sell* 12% (52% banking clients)

Restricted 2%

*For purposes of the NYSE and NASO ratings distribution disclosure requirements, our stock ratings of Outperform, Neutral, and Underperform most closely correspond to Buy, Hold, and Sell, respectively; however, the meanings are not the same, as our stock ratings are determined on a relative basis. (Please refer to definitions above.) An investor's decision to buy or sell a security should be based on investment objectives, current holdings, and other individual factors.

Credit Suisse's policy is to update research reports as it deems appropriate, based on developments with the subject company, the sector or the market that may have a material impact on the research views or opinions stated herein

Credit Suisse's policy is only to publish investment research that is impartial, independent, clear, fair and not misleading For more detail please refer to Credit Suisse's          Policies          for           Managing          Conflicts          of           Interest          in           connection           with           Investment           Research: http://www   csfb   com/research-and-analytics/disclaimer/managing—conflicts—disclaimer   html

Credit Suisse does not provide any tax advice Any statement herein regarding any US federal tax is not intended or written to be used, and cannot be used, by any taxpayer for the purposes of avoiding any penalties

Important Regional Disclosures

Singapore recipients should contact a Singapore financial adviser for any matters arising from this research report

Restrictions on certain Canadian securities are indicated by the following abbreviations: NVS--Non-Voting shares; RVS--Restricted Voting Shares; SVS--Subordinate Voting Shares

Individuals receiving this report from a Canadian investment dealer that is not affiliated with Credit Suisse should be advised that this report may not contain regulatory disclosures the non-affiliated Canadian investment dealer would be required to make if this were its own report

For  Credit Suisse  Securities  (Canada),  Inc 's  policies   and   procedures   regarding   the   dissemination   of   equity   research,   please   visit http://www csfb com/legal—terms/canada—research—policy  shtml

Credit Suisse Securities (Europe) Limited  acts as broker to RIO AX, RIO L

The following disclosed European  company/ies have estimates that comply with IFRS: AAL L,  ANTO L, BLT L, KAZ L, RIO AX, RIO L,  VED L,  XTA L

As of the date of this report, Credit Suisse acts as a market maker or liquidity provider in the equities securities that are the subject of this report

Principal is not guaranteed in the case of equities because equity prices are variable

Commission is the commission rate or the amount agreed with a customer when setting up an account or at anytime after that

To the extent this is a report authored in whole or in part by a non-U S analyst and is made available in the U S , the following are important disclosures regarding any non-U S  analyst contributors:

The non-U S research analysts listed below (if any) are not registered/qualified as research analysts with FINRA The non-U S research analysts listed below may not be associated persons of CSSU and therefore may not be subject to the NASD Rule 2711 and NYSE Rule 472 restrictions on communications with a subject company, public appearances and trading securities held by a research analyst account

• Matthew Hope, non-U S analyst, is a research analyst employed by Credit Suisse Equities (Australia) Limited

• Paul McTaggart, non-U S analyst, is a research analyst employed by Credit Suisse Equities (Australia) Limited



For  Credit  Suisse  disclosure  information  on  other  companies   mentioned   in   this   report,   please   visit   the   website   at   www credit-   suisse com/researchdisclosures or call +1 (877) 291-2683

Disclaimers continue on next page



04 August 2010

Global

Equity Research







This report is not directed to, or intended for distribution to or use by, any person or entity who is a citizen or resident of or located in any locality, state, country or other jurisdiction where such distribution, publication, availability or use would be contrary to law or regulation or which would subject Credit Suisse AG, the Swiss bank, or its subsidiaries or its affiliates ("CS") to any registration or licensing requirement within such jurisdiction All material presented in this report, unless specifically indicated otherwise, is under copyright to CS None of the material, nor its content, nor any copy of it, may be altered in any way, transmitted to, copied or distributed to any other party, without the prior express written permission of CS All trademarks, service marks and logos used in this report are trademarks or service marks or registered trademarks or service marks of CS or its affiliates

The information, tools and material presented in this report are provided to you for information purposes only and are not to be used or considered as an offer or the solicitation of an offer to sell or to buy or subscribe for securities or other financial instruments CS may not have taken any steps to ensure that the securities referred to in this report are suitable for any particular investor CS will not treat recipients as its customers by virtue of their receiving the report The investments or services contained or referred to in this report may not be suitable for you and it is recommended that you consult an independent investment advisor if you are in doubt about such investments or investment services Nothing in this report constitutes investment, legal, accounting or tax advice or a representation that any investment or strategy is suitable or appropriate to your individual circumstances or otherwise constitutes a personal recommendation to you CS does not offer advice on the tax consequences of investment and you are advised to contact an independent tax adviser Please note in particular that the bases and levels of taxation may change

CS believes the information and opinions in the Disclosure Appendix of this report are accurate and complete Information and opinions presented in the other sections of the report were obtained or derived from sources CS believes are reliable, but CS makes no representations as to their accuracy or completeness Additional information is available upon request CS accepts no liability for loss arising from the use of the material presented in this report, except that this exclusion of liability does not apply to the extent that liability arises under specific statutes or regulations applicable to CS This report is not to be relied upon in substitution for the exercise of independent judgment CS may have issued, and may in the future issue, a trading call regarding this security Trading calls are short term trading opportunities based on market events and catalysts, while stock ratings reflect investment recommendations based on expected total return over a 12-month period as defined in the disclosure section Because trading calls and stock ratings reflect different assumptions and analytical methods, trading calls may differ directionally from the stock rating In addition, CS may have issued, and may in the future issue, other reports that are inconsistent with, and reach different conclusions from, the information presented in this report Those reports reflect the different assumptions, views and analytical methods of the analysts who prepared them and CS is under no obligation to ensure that such other reports are brought to the attention of any recipient of this report CS is involved in many businesses that relate to companies mentioned in this report These businesses include specialized trading, risk arbitrage, market making, and other proprietary trading

Past performance should not be taken as an indication or guarantee of future performance, and no representation or warranty, express or implied, is made regarding future performance Information, opinions and estimates contained in this report reflect a judgement at its original date of publication by CS and are subject to change without notice The price, value of and income from any of the securities or financial instruments mentioned in this report can fall as well as rise The value of securities and financial instruments is subject to exchange rate fluctuation that may have a positive or adverse effect on the price or income of such securities or financial instruments Investors in securities such as ADR's, the values of which are influenced by currency volatility, effectively assume this risk

Structured securities are complex instruments, typically involve a high degree of risk and are intended for sale only to sophisticated investors who are capable of understanding and assuming the risks involved The market value of any structured security may be affected by changes in economic, financial and political factors (including, but not limited to, spot and forward interest and exchange rates), time to maturity, market conditions and volatility, and the credit quality of any issuer or reference issuer Any investor interested in purchasing a structured product should conduct their own investigation and analysis of the product and consult with their own professional advisers as to the risks involved in making such a purchase Some investments discussed in this report have a high level of volatility High volatility investments may experience sudden and large falls in their value causing losses when that investment is realised Those losses may equal your original investment Indeed, in the case of some investments the potential losses may exceed the amount of initial investment, in such circumstances you may be required to pay more money to support those losses Income yields from investments may fluctuate and, in consequence, initial capital paid to make the investment may be used as part of that income yield Some investments may not be readily realisable and it may be difficult to sell or realise those investments, similarly it may prove difficult for you to obtain reliable information about the value, or risks, to which such an investment is exposed

This report may provide the addresses of, or contain hyperlinks to, websites Except to the extent to which the report refers to website material of CS, CS has not reviewed the linked site and takes no responsibility for the content contained therein Such address or hyperlink (including addresses or hyperlinks to CS's own website material) is provided solely for your convenience and information and the content of the linked site does not in any way form part of this document Accessing such website or following such link through this report or CS's website shall be at your own risk

This report is issued and distributed in Europe (except Switzerland) by Credit Suisse Securities (Europe) Limited, One Cabot Square, London E14 4QJ, England, which is regulated in the United Kingdom by The Financial Services Authority ("FSA") This report is being distributed in Germany by Credit Suisse Securities (Europe) Limited Niederlassung Frankfurt am Main regulated by the Bundesanstalt fuer Finanzdienstleistungsaufsicht ("BaFin") This report is being distributed in the United States by Credit Suisse Securities (USA) LLC ; in Switzerland by Credit Suisse AG; in Canada by Credit Suisse Securities (Canada), Inc ; in Brazil by Banco de Investimentos Credit Suisse (Brasil) S A ; in Mexico by Banco Credit Suisse (M xico), S A (transactions related to the securities mentioned in this report will only be effected in compliance with applicable regulation); in Japan by Credit Suisse Securities (Japan) Limited, Financial Instrument Firm, Director-General of Kanto Local Finance Bureau (Kinsho) No 66, a member of Japan Securities Dealers Association, The Financial Futures Association of Japan, Japan Securities Investment Advisers Association; elsewhere in Asia/Pacific by whichever of the following is the appropriately authorised entity in the relevant jurisdiction: Credit Suisse (Hong Kong) Limited, Credit Suisse Equities (Australia) Limited , Credit Suisse Securities (Thailand)  Limited, Credit Suisse Securities (Malaysia)  Sdn Bhd, Credit Suisse AG, Singapore Branch, Credit Suisse Securities (India) Private Limited, Credit Suisse Securities (Europe) Limited, Seoul Branch, Credit Suisse AG, Taipei Securities Branch, PT Credit Suisse Securities Indonesia, and elsewhere in the world by the relevant authorised affiliate of the above Research on Taiwanese securities produced by Credit Suisse AG, Taipei Securities Branch has been prepared by a registered Senior Business Person Research provided to residents of Malaysia is authorised by the Head of Research for Credit Suisse Securities (Malaysia) Sdn Bhd , to whom they should direct any queries on +603 2723 2020

In jurisdictions where CS is not already registered or licensed to trade in securities, transactions will only be effected in accordance with applicable securities legislation, which will vary from jurisdiction to jurisdiction and may require that the trade be made in accordance with applicable exemptions from registration or licensing requirements Non-U S customers wishing to effect a transaction should contact a CS entity in their local jurisdiction unless governing law permits otherwise U S customers wishing to effect a transaction should do so only by contacting a representative at Credit Suisse Securities (USA) LLC in the U S

Please note that this report was originally prepared and issued by CS for distribution to their market professional and institutional investor customers Recipients who are not market professional or institutional investor customers of CS should seek the advice of their independent financial advisor prior to taking any investment decision based on this report or for any necessary explanation of its contents  This research may relate to investments or services of a person outside of the UK or to other matters which are not regulated by the FSA or in respect of which the protections of the FSA for private customers and/or the UK compensation scheme may not be available, and further details as to where this may be the case are available upon request in respect of this report

Any Nielsen Media Research material contained in this report represents Nielsen Media Research's estimates and does not represent facts NMR has neither reviewed nor approved this report and/or any of the statements made herein

If this report is being distributed by a financial institution other than Credit Suisse AG, or its affiliates, that financial institution is solely responsible for distribution Clients of that institution should contact that institution to effect a transaction in the securities mentioned in this report or require further information This report does not constitute investment advice by Credit Suisse to the clients of the distributing financial institution, and neither Credit Suisse AG, its affiliates, and their respective officers, directors and employees accept any liability whatsoever for any direct or consequential loss arising from their use of this report or its content

Copyright 2010 CREDIT SUISSE AG and/or its affiliates All rights reserved

CREDIT SUISSE EQUITIES (Australia) Limited

Australia: +61 2 8205 4400
